IP Speakers

To be future-proof and centrally controllable, IP speakers are becoming standard equipment in many calling, intercom, and bulk notification applications. Like analog speakers in the past, they are typically mounted as wall, ceiling, or ceiling tile speakers.

A speaker with an alternative connection is not the same as an IP speaker. In the end, a thousand connections can be made via the Ethernet wire that supplies IP to the speaker. To manage these links and make choices (such as which connection to present to the speaker), the IP speaker in turn requires intelligence.

A distributed processing approach replaces the matrix-centric system architecture used in IP-based audio dissemination.

There are amplifiers integrated inside the speakers

Since they employ PoE, no further power connections are needed. Simply connect the speaker to the network switch.

The paging program allows for the personalized address of each speaker. A page can be created for one individual speaker, a collection of speakers, or every speaker in the network.

An IP speaker consists of many parts. While many are not, there are several areas where traditional speakers are comparable. A good installation requires an understanding of their construction and operation. IP wall mount speakers are essentially PoE-powered integrated amplifiers.

Unlike their conventional counterparts, this makes them easier to install and allows them to operate without a requirement for an extra power connection.

Sections and Elements

The primary components of the networked speaker as well as how they communicate in a combined context. The built-in amplifier, microcontroller, D-to-A converter, and network connection are features of the network-connected speakers.

If you would like to utilize these speakers as intercoms, you may attach a microphone to them. The amplifier module within the speaker incorporates a network interface that is equipped with a customized microcontroller. The D to converter, often known as the digital-to-analog converter, amplifies the analog audio stream.

In order to power the speaker, the amplifier boosts the sound pressure level. Installation is simple because the speaker contains everything. A part of the entire network announcement system are the powered side mount speakers.To create a full audio system, you may also select separate IP amplifiers that power additional speakers or intercoms in addition to the aforementioned IP-powered speakers.

The speaker’s amplifier module has a network interface that connects to a dedicated microcomputer. The amplified analog audio stream is provided by the D-to-converter, also known as a digital-to-analog converter. In order to power the speaker, the amplifier raises the sound pressure level.  Installing it is quite simple because everything is contained within the speaker.

The entire network paging system includes the powered speakers.  In addition to these IP-powered speakers, you may build a whole audio system by choosing separate IP amplifiers that power several speakers or intercoms.  There are several varieties of IP speakers for commercial environments to choose from.

You have the option of wall-mounted, ceiling-type, bi-directional hall speakers, or speaker panels that slide into a drop ceiling panel.

Speakers’ Sound Level on PoE

The speakers that are driven by IP have a large sound output.  A wall speaker, for instance, may produce up to 99 dB at a distance of one meter.  This has to do with how loud a jackhammer or lawn mower is. The sound volume decreases with increasing distance.

Assuming that the pupils aren’t shouting, the paging noise level in a school setting should be lower than 70 dB. By lowering the speaker’s power, you can lower the volume.

An additional amplifier is typically needed for outdoor applications. Choosing IP amplifiers with more power can significantly boost the sound volume.  Greater sound levels in speakers let you spread the sound across a wider space.

Noise levels higher than 85 dB may be dangerous.  The risk varies according to your proximity to the speaker and the frequency of exposure to this loudness. Loudspeakers are often installed high on a pole and ceiling.

Digital Audio

Digital code is created from audio coming from a microphone that is connected to your computer. After being digitized, the audio is compressed before being sent to any IP speaker that has been assigned via the network.

The bandwidth and transport protocol determine the kind of encoding and compression.

Vibration Level of Powered Speakers

The loudspeaker and the digital audio bandwidth affect sound quality. A large number of IP systems utilize 64 Kbps or greater of transport capacity. These IP paging systems match the frequency ranges to speech quality sound since they believe that the user  is going to be making speech announcements rather than playing music.

Better sound quality can also be supplied for background music.  In this instance, audio is injected at up to 176 Kbps bandwidth using a network-attached audio device (IP7).

Applications for IP Speakers

Using a VoIP phone or your PC, you may make an announcement.  You may use one or more computers to make announcements with this program.

You can designate a speaker or a team of speakers to address using the program. You can communicate with a single classroom, a single building, or the whole network.

Applications for IP Speakers

Speakers Connected to IP Camera Systems

An IP video system can be utilized with powered speakers. A speaker connected to the auditory output of the IP camera (https://www.techopedia.com/definition/4694/bullet-camera) or a speaker connected to the network can be used.

People can be alerted to the need to leave a patrolled area by placing a network-attached speaker next to an IP camera. Even your dog may be yelled at.

Using paging software, you may designate a certain network speaker. Notifications may be made with extreme precision.  Some IP speakers require their specific video management software to function.

IP cameras with speakers attached

An IP camera’s audio output can also be linked to speakers. Since these are powered speakers, the amplifier needs its own power source. Some IP cameras can handle this arrangement, and it has to be supported by a video administration and recording system.
